Residential Solar - A Real World Example

I am in the process of designing and quoting a solar electrical system for a house I recently purchased.  This is a ‘Split Level’ Home of approximately 1900 sq feet.  The heating systems is electric baseboard.  I researched several local companies that provide a soup to nuts service and installation.  Some sites to find a solar installer;

http://www.findsolar.com/

http://www.getsolar.com/

Once you have selected a provider, the first step is usually a quick suitability review from the installer.  With an address, they can pull up google maps and get a view of your house, determine the orientation and roof structure.  From that initial review you get some immediate feedback about solar applicability on your house.

A site review is usually next, some firms will charge for this survey.  I imagine in their mind it is a way to determine the seriousness of customers.  The survey in my case, consisted of a 90 min review of the house.  The technician was looking at potential places for the installation, roofing and support structure, trees and shading issues, sun orientation, location of the inverters in the basement - a vented cabinet size area is needed for that and finally a review of my electric bills for the past year. This cost me $100.

About 10 days later, I received a detailed proposal.  The proposal contained pictures of the proposed installation, it’s orientation, any trees or shading that would need to be addressed, estimated energy production on my specific installation, savings and the most importantly the state and federal credits available.

A well structured ROI ( return on investment was included), and a cash flow over the life of the system were included.

The details of this installation;

Rooftop Solar Array:
Azimuth (Direction of array): 240º
Inclination: 22º (flush with roof)
Solar Access: 92%
Derate factor: 0.708
Size of solar installation: 4.94 kW DC. (26 solar panels model ES-190)

Price of Solar Installation (all costs) $35,243
Instant Savings (Commonwealth Solar Rebate) -$20,995

Upfront Cost to You $14,248

Recovered costs in year one: (Tax Credits)
State Income Tax Credit1 -$1000
Federal Income Tax Credit2 -$4274

Cost to you after rebates and tax credits $8,974

Estimated savings over 25 year life of solar panels: $85,600
Estimated increase in home value $22,500 - (based on a study by the Appraisal Institute)
Payback including increase in home value Immediate
Payback not including increase in home value 5 years
Usable life of solar panels 25+ years
Estimated annual energy production 4900 KWH
Carbon Dioxide emissions displaced per year 4510 lbs

I know that I would believe in the increase in home values in today’s economy, but the payback without that is still only 5 years.  I also don’t know if I believe the 25 year life of the panels.

I am meeting with the installer to review the proposal and get more details on what I would need to do ahead of time.  They are recommending I remove some trees, and also replace the roof prior to installing the units.

The panels are from Evergreen, which is a quality company.

Some initial questions;

Review the tax credit and or rebate process, income level qualifications, paperwork process, and timing, when does paperwork need to be submitted when would I see a check

Part guaranty and installation guaranty.

Licensing and insurance of installers

Maintenance needed

Snow and ice

What else should I be asking?

Green Fee Needed Now

Impose higher federal and or state gasoline taxes now.  Ok, I said it.  Call it a ‘Green Fee’ if you want.  Call it anything you want, but provide funds to continue the recent progress toward a greener economy.

Some background and assumptions which I used in recommending this;

BACKGROUND

The federal gas tax has been in place since 1932.  Contrary to popular belief, all monies do not go to highways or infrastructure, in fact that didn’t even start until the 50’s, prior to that it was used to fund wars.  Since 1980 the tax has increased dramatically from 4cents to 18cents per gallon.  Yet, we still have a call from Obama and congress for Infrastructure spending for roads, bridges and the like.  What have you been doing with the money Congress? Another post on that topic.

Starting in 1919 with Oregon, states started to get on the bandwagon with this new tax approach.  All states have some type of tax, whether it is a gas tax, sales tax, or excise tax (call it what you want) on gasoline.  Here is a map with all states combined taxes on gasoline from http://www.taxfoundation.org/publications/show/1054.html



On average around 40cents per gallon and $281 per person per year.

ASSUMPTIONS

  1. The US economy and consumers can handle a gasoline price of $3.50 per gallon without substantial economic slowdown
  2. The price of Gasoline will fall below $3 per gallon by the end of the year.
  3. Funding of green initiatives from both candidates will be delayed due to funding for the economic crisis and the continued war
  4. The government, federal and state, has limited spending discipline with gas tax revenue
  5. Higher retail gas prices encourage a ‘green consumer’

PROPOSAL

Impose a scaling green fee on gasoline prices. The fee would scale with the underlying per barrel of oil price.  As oil prices fall the fee increases, as it increases the fee would decrease.  The intent is to maintain a retail price around $3.50 per gallon.  The federal government would collect the fee.

Pay the Federal government a processing fee of 10% for collecting and enforcing the collections.

On a quarterly basis, the federal government will distribute the funds to an agreed upon ‘Green Investment Council’, which is managed by US Venture Capitalist firms.  Investments are made by this council in ‘green’ technologies and companies that meet the specific goals of alternative energy production, job creation, and investment return.  The overriding goal is investment return as it is with most Venture capitalists.

At no time will these fee funds take a majority position in any company, all use of these funds need to be along side private investment and will be non-voting shares.  Funds will be managed similar to the way investment funds are managed now. Contributors buy into an investment fund, expecting a return.  The revenues from this fee will be treated the same.  Congress will sit at the table as the investor.

In this way the Government is directly investing the fee from consumers in ‘Green Technology’, not funding wars or social security or corporate greed, or whatever they have been spending money on lately.  It is similar to a charity that can prove that the monies go directly to the recipient and not to the bureaucracy.  I would rather give money to those charities.

If ideas such as the Cash for clunkers http://mygreensuit.com/2008/08/03/cash-for-clunkers/

or Conservation Corps http://mygreensuit.com/2008/04/07/conservation-corps/

or Incent to Invent http://mygreensuit.com/2008/04/07/incent-to-invent/

have any standing they will need to prove themselves to the ‘Green Investment Council’

SCOPE

At current prices of $3.29 we are talking about a 20cent fee, which would equate to around $25 billion annually in the investment fund.  If the gas price actually reflects the falling oil price then we would double the investment amount per year to $50 billion.  This money, in the right hands, and please understand, Congress is not the right hands, would go a long way in funding businesses that can meet the environmental objectives, provide jobs and get the job done quicker than any government run program.

Keep it Green

Don’t stop now.  Don’t get comfortable again. Keep it Green.

Like a dieter who loses a few pounds after the first week, let’s not settle back into our old habits and think we will keep it off.

Good progress has been made making the public aware of the need to reduce our dependency on oil by looking for alternative, sustainable alternatives.  Politicians talk about it, CNN reports on it, Newspapers write about it.  Now that oil prices are falling http://mygreensuit.com/2008/10/12/oil-prices-falling/ again let’s not get lazy. We need to keep the momentum going.

The current political campaign has not discussed energy alternatives very well.  There has been too much time and discussion on more drilling, clean coal and nuclear.  Hopefully, as a country that rises to challenges, that has the best workers that are innovative and creative,  we can do better. This are a sad statement to our current capabilities if we think we have to use the crutch of coal and nuclear.  Leaving this aside, and giving kudos to the millions spent by T.Boone Pickens  www.pickensplan.com , discussion of alternatives have become mainstream.

People are expecting progress.  I am expecting progress.  From venture capitalists to scientists, to the residential owners, to commuters we are all expecting the excitement to continue.  Are we so shallow that the fact that gas prices come down 25% that we will no longer look for more efficient cars?

I think things have fundamentally changed.  The fat, greedy, energy hungry American has to change.  This is a forced diet, an intervention by the globe that must continue. We have already moved towards solutions.  Automakers have adapted their designs to be more energy efficient, venture capitalists have funded billions of dollars into the green economy.  They will expect a return on their investment.  Assuming they produce good products at a reasonable price, consumers will buy them and we can ‘Keep it Green’.

Oil Prices will continue to fall

Oil prices have fallen to below $80 a barrel as of Friday October 10.  The sell off has been in place for several weeks but was accelerated on Friday due to a widening economic crisis. I expect oil prices to continue to retreat, between $40 and $50 dollars by the end of the year would not surprise me.  Why ?

1.) The slowdown is real, this time.

Inventories are building at businesses, which means the consumer is not buying and businesses will then not need to buy new inventory.  Historically this statistic has been highly correlated to short term economic growth.  It has become somewhat less accurate as businesses have moved to ‘Just in Time’ inventories, but the fact that efficient businesses are left holding product does not bode well for the short term.  Expect big Christmas discounting.

2.) OPEC is hurting.  Not just OPEC countries but all propped up dictators and economies built on oil prices are feeling the global pinch.  The Russian stock market, which is built mostly on oil and natural gas prices, has fallen more than the US stock market over the last several weeks.  Hard to believe but, true.  The faster the rise, the faster the fall.  Venezuela is substantially slowing major social initiatives, due to slowing oil revenues.  The next OPEC meeting is November 18.  Expect OPEC Leaders to message that they are cutting production, lots of news conferences and statements and then return to their countries and exceed their production quotas.  They have nothing else.  They are a one trick pony and have been for almost 40 years, economies built of natural resources.  Boo Hoo, poor Vlady.  Go practice your Judo.

3.) Speculation works both ways.  The outcry from financial market geniuses that speculation drove the oil price so high in the first place, that the market does not work, should be eating their words now.  It is not a workable policy to have ‘one-sided capitalism’.  You can’t stop speculation or regulate oil prices from rising quickly and then remove those regulations to let it fall quickly.  You can’t let everyone win by letting housing prices rise quickly and then regulate and protect consumers by not letting them fall as quickly.  Either have consistent regulation on both sides, which will lead to a muted market, or allow the swings up and down.  People can benefit from swings either way.

4.) The ‘Green Economy’ will continue.  This is my hope that the progress we are starting to make will not get slowed down by a dropping oil price.  Read more about this in my next article.

Now if my retail gas price will reflect this price decrease I would be happy.  The per barrel price has fallen 46% since the peak.  I think my peak price per gallon was around $4.29 for regular grade.  I just paid $3.29 a gallon this week.  A decrease of 23%.  It would help the economy if this moved to the consumer quickly.

Simple Device on Cars and Trucks boosts Fuel Economy by 20%

Temple University researchers have proven out a new device to add to your fuel line in any car or truck.  This device ties into your battery and creates an electric field.  The gas line or diesel line is then routed through this device and the electrical field lowers the viscosity or basically vaporizes the gas into smaller droplets.  This ‘thinned out’ fuel is then processed normally in your car.

The Temple University team has tested this for six months on a diesel powered car and increased fuel efficiency for both highway and city driving by 20%.

They are actively working with a local trucking company to test it further.  Diesel trucks are a logical use of this, but the same technology works safely on gasoline, kerosene and other fuels.  Exciting stuff.  Innovation and Engineering will lead us out of this energy mess !

Original Publication

Solar Power from your Windows

The research and innovation teams working on Solar power are making progress with practical and effective solutions.  Multiple teams across the globe are focused on thinner materials and concentrators that can take sunlight and turn it into electricity.   Marc Baldo at MIT and John Bell at Queensland University in Australia have different approaches but fundamentally the same practical idea.  Instead of solar panels on the rooftop, use the existing window surface to collect sunlight and generate power.

John Bell and team’s work focuses on a thin film of titanium dioxide layered into the window.  This is coated with a dye to increase light absorption.  The windows have slight red hue, but are completely see through.  This same glass could be used on skylights, atriums, doors or windows.  An average home in Australia would require about 10 square meters of this glass to provide it’s power.   Assuming US houses are bigger and we get less sun (a good assumption), you are talking about 10-15 standard double hung windows.

This technology is a few years away from production and you would still need the inverters and electrical systems in the house.  But imagine the possibility for new home, mall, and office building construction.  What premium would they have to pay in price to add this power generation into their facilities?

Marc Baldo and team, approach the problem with different thinking.   It is more of a solar concentrator.  His team still uses the window surface, but instead of a film, they use the absorption dye to push the sunlight to the edges of the surface where solar cells convert the sunlight into power.  The potential for this recent discovery is absolutely huge.

Existing solar panels could add these units on and increase their efficiencies by up to %50.  Any surface where you collecting sunlight could be used.  This approach would lower the cost of solar installations, since it is using many less expensive photovoltaic cells.  Again, timing is three years away.

The discoveries are out there.  We need the initiative and money to get these to market.

Drill, Baby, Drill !

Coal companies and Oil companies are defining the future energy plans of this country.

We are at a key moment in our economic, political and environmental futures.  There is an increasing awareness of the need for energy independence and environmentally friendly energy.  We have an opportunity to solve these legitimate issues in a far reaching, planet saving, approach or fall back on the easy way.  I, for one, do not want to be part of a generation that takes the easy way.  We owe it to ourselves and our children to fight the right fight, however difficult that may be.  The right fight is one that makes these two issues into one issue.  We can find solutions that free us from foreign dictators AND are environmentally friendly.

Our energy plan for the future needs to be one that relies on efficiencies in our distribution and use of electricity, comes from renewable clean energy sources, and is local to the electrical users.  It will require innovation, new technology and a consumer commitment to make this happen.  The government needs to provide guidance, lofty goals, limited support where needed, and for the most part get out of the way.  Tom Friedman in his new book, “Hot, Flat and Crowded”, is calling it the ‘ET’ revolution or Energy Technology.  He compares it to the IT revolution which led to amazing productivity enhancements across our economy.

Whatever we call it, how we move forward on these issues will define us as a generation.

Drill, Baby, Drill, is a sad commentary of how things work now.  Oil companies and lobbyists, that both campaigns swear off as having no place in Washington, have made oil drilling a top topic and wrapped it in the, ‘Energy Plan for the Future’ blanket.  Although it may help with reducing oil dependency on the Axis of Oil, it does not do it in a way that is respectful of our planet. The more time we discuss this in public debates, the less time we spend on real solutions.  Solutions that can meet both goals of energy independence and renewable, clean energy.  Drill, baby, drill does not meet the basic principles outlined above, it is not clean, it is not local, and it is not renewable.

Let’s change the debate to a discussion of how we as Amercians can show humility, by admitting we have a problem, show fortitude, by applying our best resources to solving the problem, and show respect, for our planet and all of it’s residents.

Clean Coal ?

American Clean Power ?

American Clean Power ?

Please stop talking about Clean Coal as some kind of solution for energy independence and/or global warming issues.  It can not do either of these.  Let’s use some common sense.  Coal to replace gasoline ?  Coal to replace home heating oil?  We could build more coal fired electricity generating plants, but that does not reduce our dependency on foreign oil for the other two needs.

The picture used on the left comes from the ACCCE, a new group funded by Coal and Energy companies.  They are in the process of spending millions of dollars on ad campaigns to tell you

1.) Coal generates %50 of our electricity 2.) Coal is cleaner and can be even cleaner with investment in technology.  They run ads on TV, they have a web site http://www.americaspower.org/ Thanks for Sharing!

Clean coal !  Please.  Is there such a thing as clean coal ? It does seem peculiar to me that both Presidential candidates highlight Clean Coal, some oil drilling and nuclear plants (McCain, not Obama), for our short term energy solutions.  Other technologies are always mentioned as an afterthought, oh, yeah, “some of that Solar and Wind stuff too”. One characteristic of the commonly mentioned technologies is they exist (not clean coal), and they are backed by large existing corporate and union interests. I am sure that is just a coincidence.

Clean Coal is NOT ready for prime time.  The more we try to make old solutions work, the more money, time and energy we take away from building RENEWABLE solutions.  What is renewable about Coal, even if it was Clean.  Nothing.  It is currently plentiful so let’s use it, is the logic.  Talk about clinging to beliefs.

The same reasons many conservatives knock newer renewable energy sources, such as ‘it is not ready’, ‘it will not scale’, ‘it is to expensive’, ‘it is unproven technology’…. All apply to clean coal.

The three technologies currently being researched and mostly in a pilot phase are;

Clean it, Filter it, and Capture it.

‘IT’ is nitrous oxide, sulfur dioxide, carbon dioxide and of course your everyday mercury and other metals.

Clean it, consists of a bath for the coal prior to using.  It removes much of the sulfur, and some of nitrous oxide, BUT, it leaves a nice slurry of waste water that goes somewhere…oh yeah, in the ground, in a river, in the environment.  It does nothing to reduce carbon dioxide.

Filter it, means catalytic converter type filtering on the smokestake, or new oxygen purification systems where they cook the pollutants in a bath of oxygen.  This second approach is more effective but expensive.

Capture it, means Carbon Sequestration.  Even Al Gore talked about this during his powerpoint theater.  Is it just me, or does capturing the carbon dioxide and pumping it into the ground or better yet into active oil reserves make any sense ?  What a stupid idea.

I want to believe technology can solve most problems, and maybe it can reduce emissions so that Burning Coal produces NO pollutents.  But until that comes closer to reality, just shut up, and focus on alternative energies that actually work NOW and are clean.

Residential Wind Turbine - Vertical

I am a big proponent of vertical axis wind turbines.  I believe they have more real world uses than, their ‘bigger is better’ horizontal cousins.  Across the windy plains of the Dakotas, or Texas, the large turbines will work fine.  When you have acres and acres of land that can be dedicated to generating electricity, or where farmers can lease their land, these behemoths make sense.  But what about the rest of us ? What about the more than 70% of us that live in and around towns, and cities?  We have neighbors, we have limited space and we have costs to consider.  I think vertical will be the only way to go.

This company has made substantial progress in the market place for both wind farms, commercial and residential installations. Helix Wind, www.helixwind.com .  Unlike my previous posts on early entrants into the vertical wind market, see http://mygreensuit.com/2007/09/10/vertical-wind-turbine/ .  Helix has built products that are quiet, efficient, and look good.  I could see this is a back yard, knowing that it was producing energy and helping our environment.

See their video

Look for costs to continue to come down, as lower cost materials are used and mass production starts.  Believe it or not the height required for most of these units in a residential setting, is 30 feet above the tallest trees in your surrounding area.  Clearly, many people could get away with a simple, lower cost installation and start going green.

Miscanthus better than Switchgrass for Biofuel Production

A recent study demonstrates the capability of Miscanthus in producing ethanol.  The benefits of Switchgrass, in that in can grow in most any soil type, is perennial and easy to grow.  Advantages of MIscanthus are it grows quicker, in less acreage, and produces more ethanol.

Reprinted from ENS http://www.ens-newswire.com/ens/jul2008/2008-07-31-091.asp

CHAMPAIGN, Illinois, July 31, 2008 (ENS) - A giant perennial grass that tolerates poor soils, uses less acreage and produces more biofuel than either corn or switchgrass - it sounds too good to be true. But researchers at the University of Illinois have demonstrated that the the grass, Miscanthus x giganteus, outperforms current biofuels sources by a long shot.

Corn, switchgrass and Miscanthus have been grown side by side in experimental plots in Urbana, Illinois since 2005 in the largest field trials of their kind in the United States.

“What we’ve found with Miscanthus is that the amount of biomass generated each year would allow us to produce about two and a half times the amount of ethanol we can produce per acre of corn,” said University of Illinois crop sciences professor Stephen Long, who led the study.

University of Illinois crop sciences professor Stephen Long stands in a Miscanthus field. (Photo by Don Hamerman courtesy U. of I.)

Long is the deputy director of the BP-sponsored Energy Biosciences Institute, a multi-year, multi-institutional initiative aimed at finding low carbon or carbon neutral alternatives to petroleum fuels.

Using corn or switchgrass to produce enough ethanol to offset 20 percent of gasoline use - a current White House goal - would take 25 percent of current U.S. cropland out of food production, the researchers report.

Getting the same amount of ethanol from Miscanthus would require only 9.3 percent of current agricultural acreage.

In field trials in Illinois, researchers grew Miscanthus and switchgrass in adjoining plots. Miscanthus proved to be at least twice as productive as switchgrass.

In trials across Illinois, switchgrass, a perennial grass which, like Miscanthus, requires fewer chemical and mechanical inputs than corn, produced only about as much ethanol feedstock per acre as corn, Long said.

“It wasn’t that we didn’t know how to grow switchgrass because the yields we obtained were actually equal to the best yields that had been obtained elsewhere with switchgrass,” he said. Corn yields in Illinois are also among the best in the nation.

“One reason why Miscanthus yields more biomass than corn is that it produces green leaves about six weeks earlier in the growing season,” Long said. Miscanthus also stays green until late October in Illinois, while corn leaves wither at the end of August, he said.

The growing season for switchgrass is comparable to that of Miscanthus, but that grass is not nearly as efficient at converting sunlight to biomass as Miscanthus, found Frank Dohleman, a graduate student and co-author of the study.

“One of the criticisms of using any biomass as a biofuel source is it has been claimed that plants are not very efficient - about 0.1 percent efficiency of conversion of sunlight into biomass,” Long said. “What we show here is, on average, Miscanthus is in fact about one percent efficient, so about one percent of sunlight ends up as biomass.”

“Keep in mind that when we consider our energy use, a few hours of solar energy falling on the Earth are equal to all the energy that people use over a whole year, so you don’t really need that high an efficiency to be able to capture that in plant material and make use of it as a biofuel source,” he said.

The field trials also showed that Miscanthus is tolerant of poor soil quality, Long said.

“Our highest productivity is actually occurring in the south, on the poorest soils in the state,” he said. “So that also shows us that this type of crop may be very good for marginal land or land that is not even being used for crop production.”

Because Miscanthus is a perennial grass, it also accumulates much more carbon in the soil than an annual crop such as corn or soybeans, Long said.

“In the context of global climate change, that’s important because it means that by producing a biofuel on that land you’re taking carbon out of the atmosphere and putting it into the soil,” he said.

Using Miscanthus in an agricultural setting has not been without its challenges, explained Long. Because it is a sterile hybrid, it must be propagated by planting underground stems, called rhizomes.

This was initially a laborious process, Long said, but mechanization allows the team to plant about 15 acres a day.

In Europe, where Miscanthus has been grown for more than a decade, patented farm equipment can plant about 50 acres of Miscanthus rhizomes a day, he said.

Once established, Miscanthus returns annually without need for replanting. If harvested in December or January, after nutrients have returned to the soil, it requires little fertilizer.

This sterile form of Miscanthus has not been found to be invasive in Europe or the United States, Long said.

There are at least a dozen companies building or operating plants in the United States to produce ethanol from the non-edible parts of plants, called lignocellulosic feedstocks, and companies are propagating Miscanthus rhizomes for commercial sale, Long said.

Although research has led to improvements in productivity and growers are poised to begin using it as a biofuels crop on a large scale, Miscanthus is in its infancy as an agricultural product, Long said.

“Keep in mind that this Miscanthus is completely unimproved, so if we were to do the sorts of things that we’ve managed to do with corn, where we’ve increased its yield threefold over the last 50 years, then it’s not unreal to think that we could use even less than 10 percent of the available agricultural land,” Long said. “And if you can actually grow it on non-cropland that would be even better.”

Researchers at the University of Illinois are exploring all aspects of biofuels production, from the development of feedstocks such as Miscanthus, to planting, harvest, storage, transport, conversion to biofuels and carbon sequestration.

Copyright Environment News Service (ENS) 2008. All rights reserved.
